PDK81600-SMF Floating Underwater Fibre Optic Cable, 500 m

Name: PDK81600-SMF Floating Underwater Fibre Optic Cable, 500 m
Brand: PAIDE

Watertight Optoelectric Cables · Marine & Subsea

PDK81600-SMF floating fibre cable with one or two single-mode fibres, steel helical armour, 150 kg Kevlar braid, foam inner sheath, 6.5 mm OD, 500 m.

Request pricing → Email engineering

Project-specific customisation is available: conductor cross-section and core count, shield type, sheath colour, length and print marking can all be adapted to the operating conditions; technical parameters are subject to the specification document confirmed by both parties.

Product introduction

It uses a buoyant construction. The cable itself is lightweight and suited to underwater equipment. As the equipment dives it is dragged down with the unit, which effectively avoids the drawbacks of conventional underwater cables sinking excessively.

Model: PDK81600-SMF

Construction:

- 1 or 2 single-mode fibres

Protection: steel helical armour and PVC sheath

Strength member: Kevlar braid (150 kg)

Inner sheath: PUR foam

Outer sheath: PUR

Outer sheath colour: yellow

Temperature range: -30 °C to 90 °C

Outer diameter: 6.5±0.3 mm

Depth rating: 500 m

Features: oil resistance, flame retardancy, hydrolysis resistance, anti-microbial and UV resistance, among others.

The subsea ROV floating cable is a high-performance tether designed for remotely operated vehicles and other subsea applications. It is lightweight, robust and optimised for transport. Breaking strength is customised to the robot's requirements, and water-blocking fibre is embedded to seal any leak.

If you cannot find the model you need, please contact us at any time.
