PDK41300 2x18AWG+1SMF Tethered Drone Cable, Under 2.0 kg/100 m

Name: PDK41300 2x18AWG+1SMF Tethered Drone Cable, Under 2.0 kg/100 m
Brand: PAIDE

Tethered Drone Cables · Tethered Systems

Lightweight tethered drone cable with two 18AWG cores and one G657A2 single-mode fiber, 3.5 mm OD, under 2.0 kg per 100 m, -55 °C to 150 °C.

Request pricing → Email engineering

Custom-built to project: conductor cross-section and core count, shielding type, sheath color, length and print marking can be adjusted to the working conditions; technical parameters are subject to the specification file confirmed by both parties.

Product introduction

Fly higher, see further and do more with a durable, lightweight hybrid cable solution.

Model: PDK41300-2x18AWG+1SMF

Cable construction:

- 2 cores 18AWG (0.82 mm²)

- 1 single-mode fiber (fiber type: G657A2)

Insulation material: FEP/PTFE

Conductor: silver-plated copper / lightweight copper alloy

Sheath: high-strength aramid fiber

Outer sheath color: black

Temperature range: -55 to +150 °C

Outer diameter: 3.5 mm

Weight: less than 2.0 kg/100 m

Properties: good environmental resistance, resistant to salt spray, heat and humidity, temperature, low pressure, UV and rain.

If you need a different design, please contact us at any time.
