PDK81600-4×14AWG+2×(2×24AWG)P-200KG Floating ROV Cable, OD 17.1 mm

Name: PDK81600-4×14AWG+2×(2×24AWG)P-200KG Floating ROV Cable, OD 17.1 mm
Brand: PAIDE

Zero-Buoyancy Cables · Marine & Subsea

Floating ROV cable with four 14AWG (2.0 mm²) power cores and four signal pairs, Kevlar and water-blocking yarn fillers, PUR foam sheath, OD 17.1 mm.

Construction

4×14AWG+2×(2×24AWG)P

Tensile strength

200 kg

Request pricing → Email engineering

Built to project order: conductor cross-section and core count, shield type, sheath colour, length and print legend can all be adapted to the working conditions; technical parameters are subject to the specification document confirmed by both parties.

Product introduction

Application fields

Offshore oil and gas

Renewable energy subsea systems

Offshore equipment systems

ROV and AUV systems

Underwater cameras

Diving equipment systems

Model: PDK81600-4×14AWG+2×(2×24AWG)P-200KG

Cable construction:

- 4 cores 2.0 mm² (14AWG)

- 2 pairs 0.5 mm² (20AWG)

- 2 pairs 0.2 mm² (24AWG)

Insulation: polyethylene

Strength member: Kevlar filler (50 kg)

Filler: Kevlar + water-blocking yarn

Sheath: PUR foam

Outer sheath colour: yellow

Outer diameter: 17.1 mm

Min. bending radius: 10D

Temperature range: -40 °C to +90 °C

Features: oil resistant, flame retardant, hydrolysis resistant, antibacterial, UV resistant and so on.

This is a cable customised to customer requirements, and underwater floating cable is one of our typical cable programmes. We can customise different sizes and different types to each customer's requirements.
