PDK81600-4x2x26AWG-150KG-DJ Yellow Neutrally Buoyant ROV Tether - 7.6 mm, 500 m

Name: PDK81600-4x2x26AWG-150KG-DJ Yellow Neutrally Buoyant ROV Tether - 7.6 mm, 500 m
Brand: PAIDE

Zero-Buoyancy Cables · Marine & Subsea

Neutrally buoyant ROV tether with four 26AWG (0.14 mm2) twisted pairs, 150 kg breaking strength, foamed PUR sheath, 7.6 mm OD and 500 m depth rating.

Construction

2x26AWG

Tensile strength

150 kg

Request pricing → Email engineering

Customized per project: conductor cross-section and core count, shield type, sheath color, length and print marking can all be adapted to the operating conditions; technical parameters are subject to the specification document confirmed by both parties.

Product description

The ROV tether is a high-quality tether designed for remotely operated vehicles and other subsea applications.

Model: PDK81600-4x2x26AWG-150KG-DJ

Cable construction:

- 4 twisted pairs 26AWG (0.14 mm²)

Insulation material: PE

Tensile strength: 150 kg (Kevlar fill)

Sheath: foamed PUR

Outer sheath color: yellow

Temperature range: -30 C to +105 C

Outer diameter: 7.6 mm

Depth rating: 500 m

Features: oil resistance, flame retardance, hydrolysis resistance, resistance to bacteria and UV.

This 8-core floating cable is an ROV tether. It is neutrally buoyant, has a breaking strength of 150 kg, and incorporates water-blocking fibers to seal any leak. The core contains Kevlar yarns for strength and polyester yarns as space fillers. Both fiber types are impregnated with a water-blocking compound, so that a nick or crack in the cable does not lead to leakage.

The high-visibility yellow polyurethane foam sheath resists abrasion and provides neutral buoyancy. The cable stiffness is designed to be flexible enough to give the ROV adequate freedom of movement, yet stiff enough that it does not twist easily.

If you cannot find the model you need, please contact us at any time.
